New source files and Makefile update for Test Manual

(From yocto-docs rev: d7cff640569a5772f3c366b4136762628fca534d)

Signed-off-by: Mark Morton <mark.morton@windriver.com>
Signed-off-by: Richard Purdie <richard.purdie@linuxfoundation.org>

documentation/Makefile

@@ -358,6 +358,16 @@ STYLESHEET = $(DOC)/*.css
 endif


+ifeq ($(DOC),test-manual)
+XSLTOPTS = --xinclude
+ALLPREQ = html tarball
+TARFILES = test-manual.html test-manual-style.css \
+	   figures/test-manual-title.png figures/ab-test-cluster.png
+MANUALS = $(DOC)/$(DOC).html
+FIGURES = figures
+STYLESHEET = $(DOC)/*.css
+endif
+
 ##
 # These URI should be rewritten by your distribution's xml catalog to
 # match your locally installed XSL stylesheets.

documentation/test-manual/test-manual-customization.xsl

@@ -0,0 +1,27 @@
+<?xml version='1.0'?>
+<xsl:stylesheet xmlns:xsl="http://www.w3.org/1999/XSL/Transform" xmlns="http://www.w3.org/1999/xhtml" xmlns:fo="http://www.w3.org/1999/XSL/Format" version="1.0">
+
+  <xsl:import href="http://downloads.yoctoproject.org/mirror/docbook-mirror/docbook-xsl-1.76.1/xhtml/docbook.xsl" />
+
+<!--
+
+  <xsl:import href="../template/1.76.1/docbook-xsl-1.76.1/xhtml/docbook.xsl" />
+
+  <xsl:import href="http://docbook.sourceforge.net/release/xsl/1.76.1/xhtml/docbook.xsl" />
+
+-->
+
+  <xsl:include href="../template/permalinks.xsl"/>
+  <xsl:include href="../template/section.title.xsl"/>
+  <xsl:include href="../template/component.title.xsl"/>
+  <xsl:include href="../template/division.title.xsl"/>
+  <xsl:include href="../template/formal.object.heading.xsl"/>
+
+  <xsl:param name="html.stylesheet" select="'test-manual-style.css'" />
+  <xsl:param name="chapter.autolabel" select="1" />
+  <xsl:param name="appendix.autolabel" select="A" />
+  <xsl:param name="section.autolabel" select="1" />
+  <xsl:param name="section.label.includes.component.label" select="1" />
+  <xsl:param name="generate.id.attributes" select="1" />
+
+</xsl:stylesheet>

documentation/test-manual/test-manual-intro.xml

@@ -0,0 +1,634 @@
+<!DOCTYPE chapter PUBLIC "-//OASIS//DTD DocBook XML V4.2//EN"
+"http://www.oasis-open.org/docbook/xml/4.2/docbookx.dtd"
+[<!ENTITY % poky SYSTEM "../poky.ent"> %poky; ] >
+
+<chapter id='test-manual-intro'>
+
+<title>The Yocto Project Test Environment Manual</title>
+    <section id='test-welcome'>
+        <title>Welcome</title>
+
+        <para> Welcome to the Yocto Project Test Environment Manual! This manual is a work in
+            progress. The manual contains information about the testing environment used by the
+            Yocto Project to make sure each major and minor release works as intended. All the
+            project’s testing infrastructure and processes are publicly visible and available so
+            that the community can see what testing is being performed, how it’s being done and the
+            current status of the tests and the project at any given time. It is intended that Other
+            organizations can leverage off the process and testing environment used by the Yocto
+            Project to create their own automated, production test environment, building upon the
+            foundations from the project core. </para>
+
+        <para> Currently, the Yocto Project Test Environment Manual has no projected release date.
+            This manual is a work-in-progress and is being initially loaded with information from
+            the <ulink url="">README</ulink> files and notes from key engineers: <itemizedlist>
+                <listitem>
+                    <para>
+                        <emphasis><filename>yocto-autobuilder2</filename>:</emphasis> This <ulink
+                            url="http://git.yoctoproject.org/clean/cgit.cgi/yocto-autobuilder2/tree/README.md"
+                                ><filename>README.md</filename></ulink> is the main README which
+                        detials how to set up the Yocto Project Autobuilder. The
+                            <filename>yocto-autobuilder2</filename> repository represents the Yocto
+                        Project's console UI plugin to Buildbot and the configuration necessary to
+                        configure Buildbot to perform the testing the project requires. </para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis><filename>yocto-autobuilder-helper</filename>:</emphasis> This
+                            <ulink
+                            url="http://git.yoctoproject.org/clean/cgit.cgi/yocto-autobuilder-helper/tree/README"
+                                ><filename>README</filename></ulink> and repository contains Yocto
+                        Project Autobuilder Helper scripts and configuration. The
+                            <filename>yocto-autobuilder-helper</filename> repository contains the
+                        "glue" logic that defines which tests to run and how to run them. As a
+                        result, it can be used by any Continuous Improvement (CI) system to run
+                        builds, support getting the correct code revisions, configure builds and
+                        layers, run builds, and collect results. The code is independent of any CI
+                        system, which means the code can work Buildbot, Jenkins, or others. This
+                        repository has a branch per release of the project defining the tests to run
+                        on a per release basis.</para>
+                </listitem>
+            </itemizedlist>
+        </para>
+    </section>
+
+    <section id='test-yocto-project-autobuilder-overview'>
+        <title>Yocto Project Autobuilder Overview</title>
+
+        <para>The Yocto Project Autobuilder collectively refers to the software, tools, scripts, and
+            procedures used by the Yocto Project to test released software across supported hardware
+            in an automated and regular fashion. Basically, during the development of a Yocto
+            Project release, the Autobuilder tests if things work. The Autobuilder builds all test
+            targets and runs all the tests. </para>
+
+        <para>The Yocto Project uses now uses standard upstream  <ulink
+                url="https://docs.buildbot.net/0.9.15.post1/">Buildbot</ulink> (version 9) to drive
+            its integration and testing. Buildbot Nine has a plug-in interface that the Yocto
+            Project customizes using code from the <filename>yocto-autobuilder2</filename>
+            repository, adding its own console UI plugin. The resulting UI plug-in allows you to
+            visualize builds in a way suited to the project's needs.</para>
+
+        <para>A <filename>helper</filename> layer provides configuration and job management through
+            scripts found in the <filename>yocto-autobuilder-helper</filename> repository. The
+                <filename>helper</filename> layer contains the bulk of the build configuration
+            information and is release-specific, which makes it highly customizable on a per-project
+            basis. The layer is CI system-agnostic and contains a number of Helper scripts that can
+            generate build configurations from simple JSON files. <note>
+                <para>The project uses Buildbot for historical reasons but also because many of the
+                    project developers have knowledge of python. It is possible to use the outer
+                    layers from another Continuous Integration (CI) system such as <ulink
+                        url="https://en.wikipedia.org/wiki/Jenkins_(software)">Jenkins</ulink>
+                    instead of Buildbot. </para>
+            </note>
+        </para>
+
+        <para> The following figure shows the Yocto Project Autobuilder stack with a topology that
+            includes a controller and a cluster of workers: <imagedata
+                fileref="figures/ab-test-cluster.png" width="4.6in" depth="4.35in" align="center"
+                scalefit="1"/>
+        </para>
+    </section>
+
+    <section id='test-project-tests'>
+        <title>Yocto Project Tests - Types of Testing Overview</title>
+
+        <para>The Autobuilder tests different elements of the project by using thefollowing types of
+            tests: <itemizedlist>
+                <listitem>
+                    <para>
+                        <emphasis>Build Testing:</emphasis> Tests whether specific configurations
+                        build by varying <ulink url="&YOCTO_DOCS_REF_URL;#var-MACHINE"
+                                ><filename>MACHINE</filename></ulink>, <ulink
+                            url="&YOCTO_DOCS_REF_URL;#var-DISTRO"
+                            ><filename>DISTRO</filename></ulink>, other configuration options, and
+                        the specific target images being built (or world). Used to trigger builds of
+                        all the different test configurations on the Autobuilder. Builds usually
+                        cover many different targets for different architectures, machines, and
+                        distributions, as well as different configurations, such as different init
+                        systems. The Autobuilder tests literally hundreds of configurations and
+                        targets. <itemizedlist>
+                            <listitem>
+                                <para>
+                                    <emphasis>Sanity Checks During the Build Process:</emphasis>
+                                    Tests initiated through the <ulink
+                                        url="&YOCTO_DOCS_REF_URL;#ref-classes-insane"
+                                            ><filename>insane</filename></ulink> class. These checks
+                                    ensure the output of the builds are correct. For example, does
+                                    the ELF architecture in the generated binaries match the target
+                                    system? ARM binaries would not work in a MIPS system! </para>
+                            </listitem>
+                        </itemizedlist></para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis>Build Performance Testing:</emphasis> Tests whether or not
+                        commonly used steps during builds work efficiently and avoid regressions.
+                        Tests to time commonly used usage scenarios are run through
+                            <filename>oe-build-perf-test</filename>. These tests are run on isolated
+                        machines so that the time measurements of the tests are accurate and no
+                        other processes interfere with the timing results. The project currently
+                        tests performance on two different distributions, Fedora and Ubuntu, to
+                        ensure we have no single point of failure and can ensure the different
+                        distros work effectively. </para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis>eSDK Testing:</emphasis> Image tests initiated through the
+                        following command:
+                        <literallayout class="monospaced">
+     $ bitbake <replaceable>image</replaceable> -c testsdkext
+                    </literallayout>
+                        The tests utilize the <filename>testsdkext</filename> class and the
+                            <filename>do_testsdkext</filename> task. </para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis>Feature Testing:</emphasis> Various scenario-based tests are run
+                        through the <ulink url="&YOCTO_DOCS_REF_URL;#testing-and-quality-assurance"
+                            >OpenEmbedded Self-Test</ulink> (oe-selftest). We test oe-selftest on
+                        each of the main distrubutions we support. </para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis>Image Testing:</emphasis> Image tests initiated through the
+                        following command:
+                        <literallayout class="monospaced">
+     $ bitbake <replaceable>image</replaceable> -c testimage
+                    </literallayout>
+                        The tests utilize the <ulink
+                            url="&YOCTO_DOCS_REF_URL;#ref-classes-testimage*"
+                                ><filename>testimage*</filename></ulink> classes and the <ulink
+                            url="&YOCTO_DOCS_REF_URL;#ref-tasks-testimage"
+                                ><filename>do_testimage</filename></ulink> task. </para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis>Layer Testing:</emphasis> The Autobuilder has the possibility to
+                        test whether specific layers work with the test of the system. The layers
+                        tested may be selected by members of the project. Some key community layers
+                        are also tested periodically.</para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis>Package Testing:</emphasis> A Package Test (ptest) runs tests
+                        against packages built by the OpenEmbedded build system on the target
+                        machine. See the "<ulink
+                            url="&YOCTO_DOCS_DEV_URL;#testing-packages-with-ptest">Testing Packages
+                            With ptest</ulink>" section in the Yocto Project Development Tasks
+                        Manual and the "<ulink url="&YOCTO_WIKI_URL;/wiki/Ptest">Ptest</ulink>" Wiki
+                        page for more information on Ptest. </para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis>SDK Testing:</emphasis> Image tests initiated through the
+                        following command:
+                        <literallayout class="monospaced">
+     $ bitbake <replaceable>image</replaceable> -c testsdk
+                    </literallayout>
+                        The tests utilize the <ulink url="&YOCTO_DOCS_REF_URL;#ref-classes-testsdk"
+                                ><filename>testsdk</filename></ulink> class and the
+                            <filename>do_testsdk</filename> task. </para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis>Unit Testing:</emphasis> Unit tests on various components of the
+                        system run through <filename>oe-selftest</filename> and <ulink
+                            url="&YOCTO_DOCS_REF_URL;#testing-and-quality-assurance"
+                                ><filename>bitbake-selftest</filename></ulink>. </para>
+                </listitem>
+                <listitem>
+                    <para>
+                        <emphasis>Automatic Upgrade Helper:</emphasis> This target tests whether new
+                        versions of software are available and whether we can automatically upgrade
+                        to those new versions. If so, this target emails the maintainers with a
+                        patch to let them know this is possible.</para>
+                </listitem>
+            </itemizedlist>
+        </para>
+    </section>
+
+    <section id='test-test-mapping'>
+        <title>How Tests Map to Areas of Code</title>
+
+        <para>
+            Tests map into the codebase as follows:
+            <itemizedlist>
+                <listitem><para>
+                        <emphasis>bitbake-selftest</emphasis>: <itemizedlist>
+                            <listitem>
+                                <para>These tests are self-contained and test BitBake as well as its
+                                    APIs, which include the fetchers. The tests are located in
+                                        <filename>bitbake/lib/*/tests</filename>. </para>
+                            </listitem>
+                            <listitem>
+                                <para>From within the BitBake repository, run the following:
+                                    <literallayout class="monospaced">
+     $ bitbake-selftest
+                            </literallayout>
+                                </para>
+                            </listitem>
+                            <listitem>
+                                <para>To skip tests that access the Internet, use the
+                                        <filename>BB_SKIP_NETTEST</filename> variable when running
+                                    "bitbake-selftest" as follows:
+                                    <literallayout class="monospaced">
+     $ BB_SKIP_NETTEST=yes bitbake-selftest
+                            </literallayout>The
+                                    default output is quiet and just prints a summary of what was
+                                    run. To see more information, there is a verbose
+                                    option:<literallayout>
+     $ bitbake-selftest -v
+                             </literallayout></para>
+                                <para>Use this option when you wish to skip tests that access the
+                                    network, which are mostly necessary to test the fetcher modules.
+                                    To specify individual test modules to run, append the test
+                                    module name to the "bitbake-selftest" command. For example, to
+                                    specify the tests for the bb.data.module, run:
+                                    <literallayout class="monospaced">
+     $ bitbake-selftest bb.test.data.module
+                            </literallayout>You
+                                    can also specify individual tests by defining the full name and
+                                    module plus the class path of the test, for example:
+                                    <literallayout>
+     $ bitbake-selftest bb.tests.data.TestOverrides.test_one_override
+                             </literallayout></para>
+                            </listitem>
+                            <listitem>
+                                <para>The tests are based on <ulink
+                                        url="https://docs.python.org/3/library/unittest.html">Python
+                                        unittest</ulink>. </para>
+                            </listitem>
+                        </itemizedlist>
+                    </para></listitem>
+                <listitem><para>
+                        <emphasis>oe-selftest</emphasis>: <itemizedlist>
+                            <listitem>
+                                <para>These tests use OE to test the workflows, which include
+                                    testing specific features, behaviors of tasks, and API unit
+                                    tests. </para>
+                            </listitem>
+                            <listitem>
+                                <para>The tests can take advantage of parallelism through the "-j"
+                                    option, which can specify a number of threads to spread the
+                                    tests across. Note that all tests from a given class of tests
+                                    will run in the same thread. To parallelize large numbers of
+                                    tests you can split the class into multiple units.</para>
+                            </listitem>
+                            <listitem>
+                                <para>The tests are based on Python unittest. </para>
+                            </listitem>
+                            <listitem>
+                                <para>The code for the tests resides in
+                                        <filename>meta/lib/oeqa/selftest/cases/</filename>. </para>
+                            </listitem>
+                            <listitem>
+                                <para>To run all the tests, enter the following command:
+                                    <literallayout class="monospaced">
+     $ oe-selftest -a
+                            </literallayout>
+                                </para>
+                            </listitem>
+                            <listitem>
+                                <para>To run a specific test, use the following command form where
+                                        <replaceable>testname</replaceable> is the name of the
+                                    specific test:
+                                    <literallayout class="monospaced">
+     $ oe-selftest -r <replaceable>testname</replaceable>
+                            </literallayout>
+                                    For example, the following command would run the tinfoil getVar
+                                    API
+                                    test:<literallayout>
+     $ oe-selftest -r tinfoil.TinfoilTests.test_getvar
+                            </literallayout>It
+                                    is also possible to run a set of tests. For example the
+                                    following command will run all of the tinfoil
+                                    tests:<literallayout>
+     $ oe-selftest -r  tinfoil
+                            </literallayout></para>
+                            </listitem>
+                        </itemizedlist>
+                    </para></listitem>
+                <listitem><para>
+                    <emphasis>testimage:</emphasis>
+                    <itemizedlist>
+                        <listitem><para>
+                            These tests build an image, boot it, and run tests
+                            against the image's content.
+                            </para></listitem>
+                        <listitem><para> The code for these tests resides in <filename>meta/lib/oeqa/runtime/cases/</filename>. </para></listitem>
+                        <listitem><para>
+                            You need to set the
+                            <ulink url='&YOCTO_DOCS_REF_URL;#var-IMAGE_CLASSES'><filename>IMAGE_CLASSES</filename></ulink>
+                            variable as follows:
+                            <literallayout class='monospaced'>
+     IMAGE_CLASSES += "testimage"
+                            </literallayout>
+                            </para></listitem>
+                        <listitem><para>
+                            Run the tests using the following command form:
+                            <literallayout class='monospaced'>
+     $ bitbake <replaceable>image</replaceable> -c testimage
+                            </literallayout>
+                            </para></listitem>
+                    </itemizedlist>
+                    </para></listitem>
+                <listitem><para>
+                    <emphasis>testsdk:</emphasis>
+                    <itemizedlist>
+                        <listitem><para>These tests build an SDK, install it, and then run tests against that SDK. </para></listitem>
+                        <listitem><para>The code for these tests resides in <filename>meta/lib/oeqa/sdk/cases/</filename>. </para></listitem>
+                        <listitem><para>Run the test using the following command form:
+                                    <literallayout class="monospaced">
+     $ bitbake <replaceable>image</replaceable> -c testsdk
+                            </literallayout>
+                                </para></listitem>
+                    </itemizedlist>
+                    </para></listitem>
+                <listitem><para>
+                    <emphasis>testsdk_ext:</emphasis>
+                    <itemizedlist>
+                        <listitem><para>These tests build an extended SDK (eSDK), install that eSDK, and run tests against the eSDK. </para></listitem>
+                        <listitem><para>The code for these tests resides in <filename>meta/lib/oeqa/esdk</filename>. </para></listitem>
+                        <listitem><para>To run the tests, use the following command form:
+                                    <literallayout class="monospaced">
+     $ bitbake <replaceable>image</replaceable> -c testsdkext
+                            </literallayout>
+                                </para></listitem>
+                    </itemizedlist>
+                    </para></listitem>
+
+
+                <listitem><para>
+                    <emphasis>oe-build-perf-test:</emphasis>
+                    <itemizedlist>
+                        <listitem><para>These tests run through commonly used usage scenarios and measure the performance times. </para></listitem>
+                        <listitem><para>The code for these tests resides in <filename>meta/lib/oeqa/buildperf</filename>. </para></listitem>
+                        <listitem><para>To run the tests, use the following command form:
+                                    <literallayout class="monospaced">
+    $ oe-build-perf-test <replaceable>options</replaceable>
+                            </literallayout>The
+                                    command takes a number of options, such as where to place the
+                                    test results. The Autobuilder Helper Scripts include the
+                                        <filename>build-perf-test-wrapper</filename> script with
+                                    examples of how to use the oe-build-perf-test from the command
+                                    line.</para>
+                                <para>Use the <filename>oe-git-archive</filename> command to store
+                                    test results into a Git repository. </para>
+                                <para>Use the <filename>oe-build-perf-report</filename> command to
+                                    generate text reports and HTML reports with graphs of the
+                                    performance data. For examples, see <link linkend=""
+                                        >http://downloads.yoctoproject.org/releases/yocto/yocto-2.7/testresults/buildperf-centos7/perf-centos7.yoctoproject.org_warrior_20190414204758_0e39202.html</link>
+                                    and <link linkend=""
+                                        >http://downloads.yoctoproject.org/releases/yocto/yocto-2.7/testresults/buildperf-centos7/perf-centos7.yoctoproject.org_warrior_20190414204758_0e39202.txt</link>.</para></listitem>
+                            <listitem>
+                                <para>The tests are contained in
+                                        <filename>lib/oeqa/buildperf/test_basic.py</filename>.</para>
+                            </listitem>
+                    </itemizedlist>
+                    </para></listitem>
+
+
+
+
+            </itemizedlist>
+        </para>
+    </section>
+
+    <section id='test-examples'>
+        <title>Test Examples</title>
+
+        <para>This section provides example tests for each of the tests listed in the <link
+                linkend="test-test-mapping">How Tests Map to Areas of Code</link> section. </para>
+        <para>For oeqa tests, testcases for each area reside in the main test directory at
+                <filename>meta/lib/oeqa/selftest/cases</filename> directory.</para>
+        <para>For oe-selftest. bitbake testcases reside in the <filename>lib/bb/tests/</filename>
+            directory. </para>
+
+        <section id='bitbake-selftest-example'>
+            <title><filename>bitbake-selftest</filename></title>
+
+            <para>A simple test example from <filename>lib/bb/tests/data.py</filename> is:
+                <literallayout>
+     class DataExpansions(unittest.TestCase):
+         def setUp(self):
+             self.d = bb.data.init()
+             self.d["foo"] = "value_of_foo"
+             self.d["bar"] = "value_of_bar"
+             self.d["value_of_foo"] = "value_of_'value_of_foo'"
+
+          def test_one_var(self):
+             val =  self.d.expand("${foo}")
+             self.assertEqual(str(val), "value_of_foo")
+                     </literallayout>
+            </para>
+            <para>In this example, a <ulink url=""><filename>DataExpansions</filename></ulink> class
+                of tests is created, derived from standard python unittest. The class has a common
+                    <filename>setUp</filename> function which is shared by all the tests in the
+                class. A simple test is then added to test that when a variable is expanded, the
+                correct value is found.</para>
+            <para>Bitbake selftests are straightforward python unittest. Refer to the Python
+                unittest documentation for additional information on writing these tests at: <link
+                    linkend="">https://docs.python.org/3/library/unittest.html</link>.</para>
+        </section>
+
+        <section id='oe-selftest-example'>
+            <title><filename>oe-selftest</filename></title>
+
+            <para>These tests are more complex due to the setup required behind the scenes for full
+                builds. Rather than directly using Python's unittest, the code wraps most of the
+                standard objects. The tests can be simple, such as testing a command from within the
+                OE build environment using the following
+                example:<literallayout>
+     class BitbakeLayers(OESelftestTestCase):
+          def test_bitbakelayers_showcrossdepends(self):
+             result = runCmd('bitbake-layers show-cross-depends')
+             self.assertTrue('aspell' in result.output, msg = "No dependencies
+     were shown. bitbake-layers show-cross-depends output:
+           %s"% result.output)
+                   </literallayout></para>
+            <para>This example, taken from
+                    <filename>meta/lib/oeqa/selftest/cases/bblayers.py</filename>, creates a
+                testcase from the <ulink url=""><filename>OESelftestTestCase</filename></ulink>
+                class, derived from <filename>unittest.TestCase</filename>, which runs the
+                    <filename>bitbake-layers</filename> command and checks the output to ensure it
+                contains something we know should be here.</para>
+            <para>The <filename>oeqa.utils.commands</filename> module contains Helpers which can
+                assist with common tasks, including:<itemizedlist>
+                    <listitem>
+                        <para><emphasis>Obtaining the value of a bitbake variable:</emphasis> Use
+                                <filename>oeqa.utils.commands.get_bb_var()</filename> or use
+                                <filename>oeqa.utils.commands.get_bb_vars()</filename> for more than
+                            one variable</para>
+                    </listitem>
+                    <listitem>
+                        <para><emphasis>Running a bitbake invocation for a build:</emphasis> Use
+                                <filename>oeqa.utils.commands.bitbake()</filename></para>
+                    </listitem>
+                    <listitem>
+                        <para><emphasis>Running a command:</emphasis> Use
+                                <filename>oeqa.utils.commandsrunCmd()</filename></para>
+                    </listitem>
+                </itemizedlist></para>
+            <para>There is also a <filename>oeqa.utils.commands.runqemu()</filename> function for
+                launching the <filename>runqemu</filename> command for testing things within a
+                running, virtualized image.</para>
+            <para>You can run these tests in parallel. Parallelism works per test class, so tests
+                within a given test class should always run in the same build, while  tests in
+                different classes or modules may be split into different builds. There is no data
+                store available for these tests since the tests launch the
+                    <filename>bitbake</filename> command and exist outside of its context. As a
+                result, common bitbake library functions (bb.*) are also unavailable.</para>
+        </section>
+
+        <section id='testimage-example'>
+            <title><filename>testimage</filename></title>
+
+            <para>These tests are run once an image is up and running, either on target hardware or
+                under QEMU. As a result, they are assumed to be running in a target image
+                environment, as opposed to a host build environment. A simple example from
+                    <filename>meta/lib/oeqa/runtime/cases/python.py</filename> contains the
+                following:<literallayout>
+     class PythonTest(OERuntimeTestCase):
+         @OETestDepends(['ssh.SSHTest.test_ssh'])
+         @OEHasPackage(['python3-core'])
+         def test_python3(self):
+             cmd = "python3 -c \"import codecs; print(codecs.encode('Uryyb,
+     jbeyq', 'rot13'))\""
+             status, output = self.target.run(cmd)
+             msg = 'Exit status was not 0. Output: %s' % output
+             self.assertEqual(status, 0, msg=msg)
+                    </literallayout></para>
+            <para>In this example, the <ulink url=""><filename>OERuntimeTestCase</filename></ulink>
+                class wraps <filename>unittest.TestCase</filename>. Within the test,
+                    <filename>self.target</filename> represents the target system, where commands
+                can be run on it using the <filename>run()</filename> method. </para>
+            <para>To ensure certain test or package dependencies are met, you can use the
+                    <filename>OETestDepends</filename> and <filename>OEHasPackage</filename>
+                decorators. For example, the test in this example would only make sense if
+                python3-core is installed in the image.</para>
+        </section>
+
+        <section id='testsdk_ext-example'>
+            <title><filename>testsdk_ext</filename></title>
+
+            <para>These tests are run against built extensible SDKs (eSDKs). The tests can assume
+                that the eSDK environment has already been setup. An example from
+                    <filename>meta/lib/oeqa/sdk/cases/devtool.py</filename> contains the
+                following:<literallayout>
+     class DevtoolTest(OESDKExtTestCase):
+          @classmethod
+          def setUpClass(cls):
+          myapp_src = os.path.join(cls.tc.esdk_files_dir, "myapp")
+          cls.myapp_dst = os.path.join(cls.tc.sdk_dir, "myapp")
+          shutil.copytree(myapp_src, cls.myapp_dst)
+          subprocess.check_output(['git', 'init', '.'], cwd=cls.myapp_dst)
+          subprocess.check_output(['git', 'add', '.'], cwd=cls.myapp_dst)
+          subprocess.check_output(['git', 'commit', '-m', "'test commit'"], cwd=cls.myapp_dst)
+
+         @classmethod
+         def tearDownClass(cls):
+         shutil.rmtree(cls.myapp_dst)
+         def _test_devtool_build(self, directory):
+         self._run('devtool add myapp %s' % directory)
+         try:
+         self._run('devtool build myapp')
+         finally:
+         self._run('devtool reset myapp')
+         def test_devtool_build_make(self):
+         self._test_devtool_build(self.myapp_dst)
+                    </literallayout>In
+                this example, the <filename>devtool</filename> command is tested to see whether a
+                sample application can be built with the <filename>devtool build</filename> command
+                within the eSDK.</para>
+        </section>
+
+        <section id='testsdk-example'>
+            <title><filename>testsdk</filename></title>
+
+            <para>These tests are run against built SDKs. The tests can assume that an SDK has
+                already been extracted and its environment file has been sourced. A simple example
+                from <filename>meta/lib/oeqa/sdk/cases/python2.py</filename> contains the
+                following:<literallayout>
+     class Python3Test(OESDKTestCase):
+         def setUp(self):
+             if not (self.tc.hasHostPackage("nativesdk-python3-core") or
+                     self.tc.hasHostPackage("python3-core-native")):
+                 raise unittest.SkipTest("No python3 package in the SDK")
+
+         def test_python3(self):
+             cmd = "python3 -c \"import codecs; print(codecs.encode('Uryyb, jbeyq', 'rot13'))\""
+             output = self._run(cmd)
+             self.assertEqual(output, "Hello, world\n")
+                    </literallayout>In
+                this example, if nativesdk-python3-core has been installed into the SDK, the code
+                runs the python3 interpreter with a basic command to check it is working correctly.
+                The test would only run if python3 is installed in the SDK.</para>
+        </section>
+
+        <section id='oe-build-perf-test-example'>
+            <title><filename>oe-build-perf-test</filename></title>
+
+            <para>The performance tests usually measure how long operations take and the resource
+                utilisation as that happens. An example from
+                    <filename>meta/lib/oeqa/buildperf/test_basic.py</filename> contains the
+                following:<literallayout>
+     class Test3(BuildPerfTestCase):
+
+       def test3(self):
+           """Bitbake parsing (bitbake -p)"""
+           # Drop all caches and parse
+           self.rm_cache()
+           oe.path.remove(os.path.join(self.bb_vars['TMPDIR'], 'cache'), True)
+           self.measure_cmd_resources(['bitbake', '-p'], 'parse_1',
+                                      'bitbake -p (no caches)')
+           # Drop tmp/cache
+           oe.path.remove(os.path.join(self.bb_vars['TMPDIR'], 'cache'), True)
+           self.measure_cmd_resources(['bitbake', '-p'], 'parse_2',
+                                      'bitbake -p (no tmp/cache)')
+           # Parse with fully cached data
+           self.measure_cmd_resources(['bitbake', '-p'], 'parse_3',
+                                      'bitbake -p (cached)')
+                    </literallayout>This
+                example shows how three specific parsing timings are measured, with and without
+                various caches, to show how BitBake’s parsing performance trends over time.</para>
+        </section>
+    </section>
+    <section id='test-writing-considerations'>
+        <title>Considerations When Writing Tests</title>
+        <para>When writing good tests, there are several things to keep in mind. Since things
+            running on the Autobuilder are accessed concurrently by multiple workers, consider the
+            following:</para>
+        <formalpara>
+            <title>Running "cleanall" is not permitted</title>
+            <para>This can delete files from DL_DIR which would potentially break other builds
+                running in parallel. If this is required, DL_DIR must be set to an isolated
+                directory.</para>
+        </formalpara>
+        <formalpara>
+            <title>Running "cleansstate" is not permitted</title>
+            <para>This can delete files from SSTATE_DIR which would potentially break other builds
+                running in parallel. If this is required, SSTATE_DIR must be set to an isolated
+                directory. Alternatively, you can use the "-f" option with the
+                    <filename>bitbake</filename> command to "taint" tasks by changing the sstate
+                checksums to ensure sstate cache items will not be reused.</para>
+        </formalpara>
+        <formalpara>
+            <title>Tests should not change the metadata</title>
+            <para>This is particularly true for oe-selftests since these can run in parallel and
+                changing metadata leads to changing checksums, which confuses BitBake while running
+                in parallel. If this is necessary, copy layers to a temporary location and modify
+                them. Some tests need to change metadata, such as the devtool tests. To prevent the
+                metadate from changes, set up temporary copies of that data first.</para>
+        </formalpara>
+    </section>
+
+
+
+
+
+
+
+
+</chapter>
+<!--
+vim: expandtab tw=80 ts=4
+-->

documentation/test-manual/test-manual-style.css

@@ -0,0 +1,989 @@
+/*
+   Generic XHTML / DocBook XHTML CSS Stylesheet.
+
+   Browser wrangling and typographic design by
+      Oyvind Kolas / pippin@gimp.org
+
+   Customised for Poky by
+      Matthew Allum / mallum@o-hand.com
+
+   Thanks to:
+     Liam R. E. Quin
+     William Skaggs
+     Jakub Steiner
+
+   Structure
+   ---------
+
+   The stylesheet is divided into the following sections:
+
+       Positioning
+          Margins, paddings, width, font-size, clearing.
+       Decorations
+          Borders, style
+       Colors
+          Colors
+       Graphics
+          Graphical backgrounds
+       Nasty IE tweaks
+          Workarounds needed to make it work in internet explorer,
+          currently makes the stylesheet non validating, but up until
+          this point it is validating.
+       Mozilla extensions
+          Transparency for footer
+	  Rounded corners on boxes
+
+*/
+
+
+  /*************** /
+ /  Positioning   /
+/ ***************/
+
+body {
+  font-family: Verdana, Sans, sans-serif;
+
+  min-width: 640px;
+  width: 80%;
+  margin:  0em auto;
+  padding: 2em 5em 5em 5em;
+  color: #333;
+}
+
+h1,h2,h3,h4,h5,h6,h7 {
+  font-family: Arial, Sans;
+  color: #00557D;
+  clear: both;
+}
+
+h1 {
+  font-size: 2em;
+  text-align: left;
+  padding: 0em 0em 0em 0em;
+  margin: 2em 0em 0em 0em;
+}
+
+h2.subtitle {
+  margin: 0.10em 0em 3.0em 0em;
+  padding: 0em 0em 0em 0em;
+  font-size: 1.8em;
+  padding-left: 20%;
+  font-weight: normal;
+  font-style: italic;
+}
+
+h2 {
+  margin: 2em 0em 0.66em 0em;
+  padding: 0.5em 0em 0em 0em;
+  font-size: 1.5em;
+  font-weight: bold;
+}
+
+h3.subtitle {
+  margin: 0em 0em 1em 0em;
+  padding: 0em 0em 0em 0em;
+  font-size: 142.14%;
+  text-align: right;
+}
+
+h3 {
+  margin: 1em 0em 0.5em 0em;
+  padding: 1em 0em 0em 0em;
+  font-size: 140%;
+  font-weight: bold;
+}
+
+h4 {
+  margin: 1em 0em 0.5em 0em;
+  padding: 1em 0em 0em 0em;
+  font-size: 120%;
+  font-weight: bold;
+}
+
+h5 {
+  margin: 1em 0em 0.5em 0em;
+  padding: 1em 0em 0em 0em;
+  font-size: 110%;
+  font-weight: bold;
+}
+
+h6 {
+  margin: 1em 0em 0em 0em;
+  padding: 1em 0em 0em 0em;
+  font-size: 110%;
+  font-weight: bold;
+}
+
+.authorgroup {
+  background-color: transparent;
+  background-repeat: no-repeat;
+  padding-top: 256px;
+  background-image: url("figures/test-manual-title.png");
+  background-position: left top;
+  margin-top: -256px;
+  padding-right: 50px;
+  margin-left: 0px;
+  text-align: right;
+  width: 740px;
+}
+
+h3.author {
+  margin: 0em 0me 0em 0em;
+  padding: 0em 0em 0em 0em;
+  font-weight: normal;
+  font-size: 100%;
+  color: #333;
+  clear: both;
+}
+
+.author tt.email {
+  font-size: 66%;
+}
+
+.titlepage hr {
+  width: 0em;
+  clear: both;
+}
+
+.revhistory {
+  padding-top: 2em;
+  clear: both;
+}
+
+.toc,
+.list-of-tables,
+.list-of-examples,
+.list-of-figures {
+  padding: 1.33em 0em 2.5em 0em;
+  color: #00557D;
+}
+
+.toc p,
+.list-of-tables p,
+.list-of-figures p,
+.list-of-examples p {
+  padding: 0em 0em 0em 0em;
+  padding: 0em 0em 0.3em;
+  margin: 1.5em 0em 0em 0em;
+}
+
+.toc p b,
+.list-of-tables p b,
+.list-of-figures p b,
+.list-of-examples p b{
+  font-size: 100.0%;
+  font-weight: bold;
+}
+
+.toc dl,
+.list-of-tables dl,
+.list-of-figures dl,
+.list-of-examples dl {
+  margin: 0em 0em 0.5em 0em;
+  padding: 0em 0em 0em 0em;
+}
+
+.toc dt {
+  margin: 0em 0em 0em 0em;
+  padding: 0em 0em 0em 0em;
+}
+
+.toc dd {
+  margin: 0em 0em 0em 2.6em;
+  padding: 0em 0em 0em 0em;
+}
+
+div.glossary dl,
+div.variablelist dl {
+}
+
+.glossary dl dt,
+.variablelist dl dt,
+.variablelist dl dt span.term {
+  font-weight: normal;
+  width: 20em;
+  text-align: right;
+}
+
+.variablelist dl dt {
+  margin-top: 0.5em;
+}
+
+.glossary dl dd,
+.variablelist dl dd {
+  margin-top: 0em;
+  margin-left: 25.5em;
+}
+
+.glossary dd p,
+.variablelist dd p {
+  margin-top: 0em;
+  margin-bottom: 1em;
+}
+
+
+div.calloutlist table td {
+  padding: 0em 0em 0em 0em;
+  margin: 0em 0em 0em 0em;
+}
+
+div.calloutlist table td p {
+  margin-top: 0em;
+  margin-bottom: 1em;
+}
+
+div p.copyright {
+  text-align: left;
+}
+
+div.legalnotice p.legalnotice-title {
+  margin-bottom: 0em;
+}
+
+p {
+  line-height: 1.5em;
+  margin-top: 0em;
+
+}
+
+dl {
+  padding-top: 0em;
+}
+
+hr {
+  border: solid 1px;
+}
+
+
+.mediaobject,
+.mediaobjectco {
+  text-align: center;
+}
+
+img {
+  border: none;
+}
+
+ul {
+  padding: 0em 0em 0em 1.5em;
+}
+
+ul li {
+  padding: 0em 0em 0em 0em;
+}
+
+ul li p {
+  text-align: left;
+}
+
+table {
+  width :100%;
+}
+
+th {
+  padding: 0.25em;
+  text-align: left;
+  font-weight: normal;
+  vertical-align: top;
+}
+
+td {
+  padding: 0.25em;
+  vertical-align: top;
+}
+
+p a[id] {
+  margin: 0px;
+  padding: 0px;
+  display: inline;
+  background-image: none;
+}
+
+a {
+  text-decoration: underline;
+  color: #444;
+}
+
+pre {
+    overflow: auto;
+}
+
+a:hover {
+  text-decoration: underline;
+  /*font-weight: bold;*/
+}
+
+/* This style defines how the permalink character
+   appears by itself and when hovered over with
+   the mouse. */
+
+[alt='Permalink'] { color: #eee; }
+[alt='Permalink']:hover { color: black; }
+
+
+div.informalfigure,
+div.informalexample,
+div.informaltable,
+div.figure,
+div.table,
+div.example {
+  margin: 1em 0em;
+  padding: 1em;
+  page-break-inside: avoid;
+}
+
+
+div.informalfigure p.title b,
+div.informalexample p.title b,
+div.informaltable p.title b,
+div.figure p.title b,
+div.example p.title b,
+div.table p.title b{
+    padding-top: 0em;
+    margin-top: 0em;
+    font-size: 100%;
+    font-weight: normal;
+}
+
+.mediaobject .caption,
+.mediaobject .caption p  {
+  text-align: center;
+  font-size: 80%;
+  padding-top: 0.5em;
+  padding-bottom: 0.5em;
+}
+
+.epigraph {
+  padding-left: 55%;
+  margin-bottom: 1em;
+}
+
+.epigraph p {
+  text-align: left;
+}
+
+.epigraph .quote {
+  font-style: italic;
+}
+.epigraph .attribution {
+  font-style: normal;
+  text-align: right;
+}
+
+span.application {
+  font-style: italic;
+}
+
+.programlisting {
+  font-family: monospace;
+  font-size: 80%;
+  white-space: pre;
+  margin: 1.33em 0em;
+  padding: 1.33em;
+}
+
+.tip,
+.warning,
+.caution,
+.note {
+  margin-top: 1em;
+  margin-bottom: 1em;
+
+}
+
+/* force full width of table within div */
+.tip table,
+.warning table,
+.caution table,
+.note table {
+  border: none;
+  width: 100%;
+}
+
+
+.tip table th,
+.warning table th,
+.caution table th,
+.note table th {
+  padding: 0.8em 0.0em 0.0em 0.0em;
+  margin : 0em 0em 0em 0em;
+}
+
+.tip p,
+.warning p,
+.caution p,
+.note p {
+  margin-top: 0.5em;
+  margin-bottom: 0.5em;
+  padding-right: 1em;
+  text-align: left;
+}
+
+.acronym {
+  text-transform: uppercase;
+}
+
+b.keycap,
+.keycap {
+  padding: 0.09em 0.3em;
+  margin: 0em;
+}
+
+.itemizedlist li {
+  clear: none;
+}
+
+.filename {
+  font-size: medium;
+  font-family: Courier, monospace;
+}
+
+
+div.navheader, div.heading{
+  position: absolute;
+  left: 0em;
+  top: 0em;
+  width: 100%;
+  background-color: #cdf;
+  width: 100%;
+}
+
+div.navfooter, div.footing{
+  position: fixed;
+  left: 0em;
+  bottom: 0em;
+  background-color: #eee;
+  width: 100%;
+}
+
+
+div.navheader td,
+div.navfooter td {
+  font-size: 66%;
+}
+
+div.navheader table th {
+  /*font-family: Georgia, Times, serif;*/
+  /*font-size: x-large;*/
+  font-size: 80%;
+}
+
+div.navheader table {
+  border-left: 0em;
+  border-right: 0em;
+  border-top: 0em;
+  width: 100%;
+}
+
+div.navfooter table {
+  border-left: 0em;
+  border-right: 0em;
+  border-bottom: 0em;
+  width: 100%;
+}
+
+div.navheader table td a,
+div.navfooter table td a {
+  color: #777;
+  text-decoration: none;
+}
+
+/* normal text in the footer */
+div.navfooter table td {
+  color: black;
+}
+
+div.navheader table td a:visited,
+div.navfooter table td a:visited {
+  color: #444;
+}
+
+
+/* links in header and footer */
+div.navheader table td a:hover,
+div.navfooter table td a:hover {
+  text-decoration: underline;
+  background-color: transparent;
+  color: #33a;
+}
+
+div.navheader hr,
+div.navfooter hr {
+  display: none;
+}
+
+
+.qandaset tr.question td p {
+  margin: 0em 0em 1em 0em;
+  padding: 0em 0em 0em 0em;
+}
+
+.qandaset tr.answer td p {
+  margin: 0em 0em 1em 0em;
+  padding: 0em 0em 0em 0em;
+}
+.answer td {
+  padding-bottom: 1.5em;
+}
+
+.emphasis {
+  font-weight: bold;
+}
+
+
+  /************* /
+ / decorations  /
+/ *************/
+
+.titlepage {
+}
+
+.part .title {
+}
+
+.subtitle {
+    border: none;
+}
+
+/*
+h1 {
+  border: none;
+}
+
+h2 {
+  border-top: solid 0.2em;
+  border-bottom: solid 0.06em;
+}
+
+h3 {
+  border-top: 0em;
+  border-bottom: solid 0.06em;
+}
+
+h4 {
+  border: 0em;
+  border-bottom: solid 0.06em;
+}
+
+h5 {
+  border: 0em;
+}
+*/
+
+.programlisting {
+  border: solid 1px;
+}
+
+div.figure,
+div.table,
+div.informalfigure,
+div.informaltable,
+div.informalexample,
+div.example {
+  border: 1px solid;
+}
+
+
+
+.tip,
+.warning,
+.caution,
+.note {
+  border: 1px solid;
+}
+
+.tip table th,
+.warning table th,
+.caution table th,
+.note table th {
+  border-bottom: 1px solid;
+}
+
+.question td {
+  border-top: 1px solid black;
+}
+
+.answer {
+}
+
+
+b.keycap,
+.keycap {
+  border: 1px solid;
+}
+
+
+div.navheader, div.heading{
+  border-bottom: 1px solid;
+}
+
+
+div.navfooter, div.footing{
+  border-top: 1px solid;
+}
+
+  /********* /
+ /  colors  /
+/ *********/
+
+body {
+  color: #333;
+  background: white;
+}
+
+a {
+  background: transparent;
+}
+
+a:hover {
+  background-color: #dedede;
+}
+
+
+h1,
+h2,
+h3,
+h4,
+h5,
+h6,
+h7,
+h8 {
+  background-color: transparent;
+}
+
+hr {
+  border-color: #aaa;
+}
+
+
+.tip, .warning, .caution, .note {
+  border-color: #fff;
+}
+
+
+.tip table th,
+.warning table th,
+.caution table th,
+.note table th {
+  border-bottom-color: #fff;
+}
+
+
+.warning {
+  background-color: #f0f0f2;
+}
+
+.caution {
+  background-color: #f0f0f2;
+}
+
+.tip {
+  background-color: #f0f0f2;
+}
+
+.note {
+  background-color: #f0f0f2;
+}
+
+.glossary dl dt,
+.variablelist dl dt,
+.variablelist dl dt span.term {
+  color: #044;
+}
+
+div.figure,
+div.table,
+div.example,
+div.informalfigure,
+div.informaltable,
+div.informalexample {
+  border-color: #aaa;
+}
+
+pre.programlisting {
+  color: black;
+  background-color: #fff;
+  border-color: #aaa;
+  border-width: 2px;
+}
+
+.guimenu,
+.guilabel,
+.guimenuitem {
+  background-color: #eee;
+}
+
+
+b.keycap,
+.keycap {
+  background-color: #eee;
+  border-color: #999;
+}
+
+
+div.navheader {
+  border-color: black;
+}
+
+
+div.navfooter {
+  border-color: black;
+}
+
+.writernotes {
+  color: red;
+}
+
+
+  /*********** /
+ /  graphics  /
+/ ***********/
+
+/*
+body {
+  background-image: url("images/body_bg.jpg");
+  background-attachment: fixed;
+}
+
+.navheader,
+.note,
+.tip {
+  background-image: url("images/note_bg.jpg");
+  background-attachment: fixed;
+}
+
+.warning,
+.caution {
+  background-image: url("images/warning_bg.jpg");
+  background-attachment: fixed;
+}
+
+.figure,
+.informalfigure,
+.example,
+.informalexample,
+.table,
+.informaltable {
+  background-image: url("images/figure_bg.jpg");
+  background-attachment: fixed;
+}
+
+*/
+h1,
+h2,
+h3,
+h4,
+h5,
+h6,
+h7{
+}
+
+/*
+Example of how to stick an image as part of the title.
+
+div.article .titlepage .title
+{
+  background-image: url("figures/white-on-black.png");
+  background-position: center;
+  background-repeat: repeat-x;
+}
+*/
+
+div.preface .titlepage .title,
+div.colophon .title,
+div.chapter .titlepage .title,
+div.article .titlepage .title
+{
+}
+
+div.section div.section .titlepage .title,
+div.sect2 .titlepage .title {
+    background: none;
+}
+
+
+h1.title {
+  background-color: transparent;
+  background-image: url("figures/test-title.png");
+  background-repeat: no-repeat;
+  height: 256px;
+  text-indent: -9000px;
+  overflow:hidden;
+}
+
+h2.subtitle {
+  background-color: transparent;
+  text-indent: -9000px;
+  overflow:hidden;
+  width: 0px;
+  display: none;
+}
+
+  /*************************************** /
+ /  pippin.gimp.org specific alterations  /
+/ ***************************************/
+
+/*
+div.heading, div.navheader {
+  color: #777;
+  font-size: 80%;
+  padding: 0;
+  margin: 0;
+  text-align: left;
+  position: absolute;
+  top: 0px;
+  left: 0px;
+  width: 100%;
+  height: 50px;
+  background: url('/gfx/heading_bg.png') transparent;
+  background-repeat: repeat-x;
+  background-attachment: fixed;
+  border: none;
+}
+
+div.heading a {
+  color: #444;
+}
+
+div.footing, div.navfooter {
+  border: none;
+  color: #ddd;
+  font-size: 80%;
+  text-align:right;
+
+  width: 100%;
+  padding-top: 10px;
+  position: absolute;
+  bottom: 0px;
+  left: 0px;
+
+  background: url('/gfx/footing_bg.png') transparent;
+}
+*/
+
+
+
+  /****************** /
+ /  nasty ie tweaks  /
+/ ******************/
+
+/*
+div.heading, div.navheader {
+  width:expression(document.body.clientWidth + "px");
+}
+
+div.footing, div.navfooter {
+  width:expression(document.body.clientWidth + "px");
+  margin-left:expression("-5em");
+}
+body {
+  padding:expression("4em 5em 0em 5em");
+}
+*/
+
+  /**************************************** /
+ / mozilla vendor specific css extensions  /
+/ ****************************************/
+/*
+div.navfooter, div.footing{
+  -moz-opacity: 0.8em;
+}
+
+div.figure,
+div.table,
+div.informalfigure,
+div.informaltable,
+div.informalexample,
+div.example,
+.tip,
+.warning,
+.caution,
+.note {
+  -moz-border-radius: 0.5em;
+}
+
+b.keycap,
+.keycap {
+  -moz-border-radius: 0.3em;
+}
+*/
+
+table tr td table tr td {
+  display: none;
+}
+
+
+hr {
+  display: none;
+}
+
+table {
+  border: 0em;
+}
+
+ .photo {
+  float: right;
+  margin-left:   1.5em;
+  margin-bottom: 1.5em;
+  margin-top: 0em;
+  max-width:      17em;
+  border:     1px solid gray;
+  padding:    3px;
+  background: white;
+}
+ .seperator {
+   padding-top: 2em;
+   clear: both;
+  }
+
+  #validators {
+      margin-top: 5em;
+      text-align: right;
+      color: #777;
+  }
+  @media print {
+      body {
+          font-size: 8pt;
+      }
+      .noprint {
+          display: none;
+      }
+  }
+
+
+.tip,
+.note {
+   background: #f0f0f2;
+   color: #333;
+   padding: 20px;
+   margin: 20px;
+}
+
+.tip h3,
+.note h3 {
+   padding: 0em;
+   margin: 0em;
+   font-size: 2em;
+   font-weight: bold;
+   color: #333;
+}
+
+.tip a,
+.note a {
+   color: #333;
+   text-decoration: underline;
+}
+
+.footnote {
+   font-size: small;
+   color: #333;
+}
+
+/* Changes the announcement text */
+.tip h3,
+.warning h3,
+.caution h3,
+.note h3 {
+   font-size:large;
+   color: #00557D;
+}

documentation/test-manual/test-manual-test-process.xml

@@ -0,0 +1,109 @@
+<!DOCTYPE chapter PUBLIC "-//OASIS//DTD DocBook XML V4.2//EN"
+"http://www.oasis-open.org/docbook/xml/4.2/docbookx.dtd"
+[<!ENTITY % poky SYSTEM "../poky.ent"> %poky; ] >
+
+<chapter id='test-manual-test-process'>
+
+<title>Project Testing and Release Process</title>
+    <section id='test-daily-devel'>
+        <title>Day to Day Development</title>
+
+        <para>This section details how the project tests changes, through automation on the
+            Autobuilder or with the assistance of QA teams, through to making releases.</para>
+
+        <para>The project aims to test changes against our test matrix before those changes are
+            merged into the master branch. As such, changes are queued up in batches either in the
+                <filename>master-next</filename> branch in the main trees, or in user trees such as
+                <filename>ross/mut</filename> in <filename>poky-contrib</filename> (Ross Burton
+            helps review and test patches and this is his testing tree).</para>
+        <para>We have two broad categories of test builds, including "full" and "quick". On the
+            Autobuilder, these can be seen as "a-quick" and "a-full", simply for ease of sorting in
+            the UI. Use our Autobuilder console view to see where me manage most test-related items,
+            available at: <link linkend=""
+                >https://autobuilder.yoctoproject.org/typhoon/#/console</link>.</para>
+        <para>Builds are triggered manually when the test branches are ready. The builds are
+            monitored by the SWAT team. For additional information, see <link linkend=""
+                >https://wiki.yoctoproject.org/wiki/Yocto_Build_Failure_Swat_Team</link>. If
+            successful, the changes would usually be merged to the <filename>master</filename>
+            branch. If not successful, someone would respond to the changes on the mailing list
+            explaining that there was a failure in testing. The choice of quick or full would depend
+            on the type of changes and the speed with which the result was required.</para>
+        <para>The Autobuilder does build the <filename>master</filename> branch once daily for
+            several reasons, in particular, to ensure the current <filename>master</filename> branch
+            does build, but also to keep <filename>yocto-testresults</filename> (<link linkend=""
+                >http://git.yoctoproject.org/cgit.cgi/yocto-testresults/</link>), buildhistory
+                (<link linkend="">http://git.yoctoproject.org/cgit.cgi/poky-buildhistory/</link>),
+            and our sstate up to date. On the weekend, there is a master-next build instead to
+            ensure the test results are updated for the less frequently run targets.</para>
+        <para>Performance builds (buildperf-* targets in the console) are triggered separately every
+            six hours and automatically push their results to the buildstats repository at: <link
+                linkend="">http://git.yoctoproject.org/cgit.cgi/yocto-buildstats/</link>. </para>
+        <para>The 'quick' targets have been selected to be the ones which catch the most failures or
+            give the most valuable data. We run 'fast' ptests in this case for example but not the
+            ones which take a long time. The quick target doesn't include *-lsb builds for all
+            architectures, some world builds and doesn't trigger performance tests or ltp testing.
+            The full build includes all these things and is slower but more comprehensive.</para>
+    </section>
+
+    <section id='test-yocto-project-autobuilder-overview'>
+        <title>Release Builds</title>
+
+        <para>The project typically has two major releases a year with a six month cadence in April
+            and October. Between these there would be a number of milestone releases (usually four)
+            with the final one being stablization only along with point releases of our stable
+            branches.</para>
+        <para>The build and release process for these project releases is similar to that in <link
+                linkend="test-daily-devel">Day to Day Development</link>, in that the a-full target
+            of the Autobuilder is used but in addition the form is configured to generate and
+            publish artefacts and the milestone number, version, release candidate number and other
+            information is entered. The box to "generate an email to QA"is also checked.</para>
+        <para>When the build completes, an email is sent out using the send-qa-email script in the
+                <filename>yocto-autobuilder-helper</filename> repository to the list of people
+            configured for that release. Release builds are placed into a directory in <link
+                linkend="">https://autobuilder.yocto.io/pub/releases</link> on the Autobuilder which
+            is included in the email. The process from here is more manual and control is
+            effectively passed to release engineering. The next steps include:<itemizedlist>
+                <listitem>
+                    <para>QA teams respond to the email saying which tests they plan to run and when
+                        the results will be available.</para>
+                </listitem>
+                <listitem>
+                    <para>QA teams run their tests and share their results in the yocto-
+                        testresults-contrib repository, along with a summary of their findings.
+                    </para>
+                </listitem>
+                <listitem>
+                    <para>Release engineering prepare the release as per their process. </para>
+                </listitem>
+                <listitem>
+                    <para>Test results from the QA teams are included into the release in separate
+                        directories and also uploaded to the yocto-testresults repository alongside
+                        the other test results for the given revision.</para>
+                </listitem>
+                <listitem>
+                    <para>The QA report in the final release is regenerated using resulttool to
+                        include the new test results and the test summaries from the teams (as
+                        headers to the generated report).</para>
+                </listitem>
+                <listitem>
+                    <para>The release is checked against the release checklist and release readiness
+                        criteria.</para>
+                </listitem>
+                <listitem>
+                    <para>A final decision on whether to release is made by the YP TSC who have
+                        final oversight on release readiness.</para>
+                </listitem>
+            </itemizedlist></para>
+    </section>
+
+
+
+
+
+
+
+
+</chapter>
+<!--
+vim: expandtab tw=80 ts=4
+-->

documentation/test-manual/test-manual-understand-autobuilder.xml

@@ -0,0 +1,312 @@
+<!DOCTYPE chapter PUBLIC "-//OASIS//DTD DocBook XML V4.2//EN"
+"http://www.oasis-open.org/docbook/xml/4.2/docbookx.dtd"
+[<!ENTITY % poky SYSTEM "../poky.ent"> %poky; ] >
+
+<chapter id='test-manual-understand-autobuilder'>
+
+<title>Understanding the Yocto Project Autobuilder</title>
+    <section>
+        <title>Execution Flow within the Autobuilder</title>
+        <para>The “a-full” and “a-quick” targets are the usual entry points into the Autobuilder and
+            it makes sense to follow the process through the system starting there. This is best
+            visualised from the Autobuilder Console view (<link linkend=""
+                >https://autobuilder.yoctoproject.org/typhoon/#/console</link>). </para>
+        <para>Each item along the top of that view represents some “target build” and these targets
+            are all run in parallel. The ‘full’ build will trigger the majority of them, the “quick”
+            build will trigger some subset of them. The Autobuilder effectively runs whichever
+            configuration is defined for each of those targets on a seperate buildbot worker. To
+            understand the configuration, you need to look at the entry on
+                <filename>config.json</filename> file within the
+                <filename>yocto-autobuilder-helper</filename> repository. The targets are defined in
+            the ‘overrides’ section, a quick example could be qemux86-64 which looks
+            like:<literallayout>
+     "qemux86-64" : {
+         "MACHINE" : "qemux86-64",
+         "TEMPLATE" : "arch-qemu",
+         "step1" : {
+             "extravars" : [
+                  "IMAGE_FSTYPES_append = ' wic wic.bmap'"
+             ]
+         }
+     },
+                    </literallayout>And
+            to expand that, you need the “arch-qemu” entry from the “templates” section, which looks
+            like:<literallayout>
+     "arch-qemu" : {
+         "BUILDINFO" : true,
+         "BUILDHISTORY" : true,
+         "step1" : {
+             "BBTARGETS" : "core-image-sato core-image-sato-dev core-image-sato-sdk core-image-minimal core-image-minimal-dev core-image-sato:do_populate_sdk",
+             "SANITYTARGETS" : "core-image-minimal:do_testimage core-image-sato:do_testimage core-image-sato-sdk:do_testimage core-image-sato:do_testsdk"
+         },
+         "step2" : {
+             "SDKMACHINE" : "x86_64",
+             "BBTARGETS" : "core-image-sato:do_populate_sdk core-image-minimal:do_populate_sdk_ext core-image-sato:do_populate_sdk_ext",
+             "SANITYTARGETS" : "core-image-sato:do_testsdk core-image-minimal:do_testsdkext core-image-sato:do_testsdkext"
+         },
+         "step3" : {
+             "BUILDHISTORY" : false,
+             "EXTRACMDS" : ["${SCRIPTSDIR}/checkvnc; DISPLAY=:1 oe-selftest ${HELPERSTMACHTARGS} -j 15"],
+             "ADDLAYER" : ["${BUILDDIR}/../meta-selftest"]
+         }
+     },
+                    </literallayout>Combining
+            these two entries you can see that “qemux86-64” is a three step build where the “bitbake
+            BBTARGETS” would be run, then “bitbake SANITYTARGETS” for each step; all for
+            MACHINE=”qemx86-64” but with differing SDKMACHINE settings. In step 1 an extra variable
+            is added to the <filename>auto.conf</filename> file to enable wic image
+            generation.</para>
+        <para>While not every detail of this is covered here, you can see how the templating
+            mechanism allows quite complex configurations to be built up yet allows duplication and
+            repetition to be kept to a minimum.</para>
+        <para>The different build targets are designed to allow for parallelisation, so different
+            machines are usually built in parallel, operations using the same machine and metadata
+            are built sequentially, with the aim of trying to optimise build efficiency as much as
+            possible.</para>
+        <para>The <filename>config.json</filename> file is processed by the scripts in the Helper
+            repository in the <filename>scripts</filename> directory. The following  section details
+            how this works.</para>
+    </section>
+
+    <section id='test-autobuilder-target-exec-overview'>
+        <title>Autobuilder Target Execution Overview</title>
+
+        <para>For each given target in a build, the Autobuilder executes several steps. These are
+            configured in <filename>yocto-autobuilder2/builders.py</filename> and roughly consist
+            of: <orderedlist>
+                <listitem id='test-list-tgt-exec-clobberdir'>
+                    <para><emphasis>Run <filename>clobberdir</filename></emphasis></para>
+                    <para>This cleans out any previous build. Old builds are left around to allow
+                        easier debugging of failed builds. For additional information, see <link
+                            linkend="test-clobberdir"><filename>clobberdir</filename></link>.</para>
+                </listitem>
+                <listitem>
+                    <para><emphasis>Obtain yocto-autobuilder-helper</emphasis></para>
+                    <para>This step clones the <filename>yocto-autobuilder-helper</filename> git
+                        repository. This is necessary to prevent the requirement to maintain all the
+                        release or project-specific code within Buildbot. The branch chosen matches
+                        the release being built so we can support older releases and still make
+                        changes in newer ones.</para>
+                </listitem>
+                <listitem>
+                    <para><emphasis>Write layerinfo.json</emphasis></para>
+                    <para>This transfers data in the Buildbot UI when the build was configured to
+                        the Helper.</para>
+                </listitem>
+                <listitem>
+                    <para><emphasis>Call scripts/shared-repo-unpack</emphasis></para>
+                    <para>This is a call into the Helper scripts to set up a checkout of all the
+                        pieces this build might need. It might clone the BitBake repository and the
+                        OpenEmbedded-Core repository. It may clone the Poky repository, as well as
+                        additional layers. It will use the data from the
+                            <filename>layerinfo.json</filename> file to help understand the
+                        configuration. It will also use a local cache of repositories to speed up
+                        the clone checkouts. For additional information, see <link
+                            linkend="test-autobuilder-clone-cache">Autobuilder Clone
+                        Cache</link>.</para>
+                    <para>This step has two possible modes of operation. If the build is part of a
+                        parent build, its possible that all the repositories needed may already be
+                        available, ready in a pre-prepared directory. An "a-quick" or "a-full" build
+                        would prepare this before starting the other sub-target builds. This is done
+                        for two reasons:<itemizedlist>
+                            <listitem>
+                                <para>the upstream may change during a build, for example, from a
+                                    forced push and this ensures we have matching content for the
+                                    whole build</para>
+                            </listitem>
+                            <listitem>
+                                <para>if 15 Workers all tried to pull the same data from the same
+                                    repos, we can hit resource limits on upstream servers as they
+                                    can think they are under some kind of network attack</para>
+                            </listitem>
+                        </itemizedlist>This pre-prepared directory is shared among the Workers over
+                        NFS. If the build is an individual build and there is no "shared" directory
+                        available, it would clone from the cache and the upstreams as necessary.
+                        This is considered the fallback mode.</para>
+                </listitem>
+                <listitem>
+                    <para><emphasis>Call scripts/run-config</emphasis></para>
+                    <para>This is another call into the Helper scripts where its expected that the
+                        main functionality of this target will be executed.</para>
+                </listitem>
+            </orderedlist></para>
+    </section>
+    <section id='test-autobuilder-tech'>
+        <title>Autobuilder Technology</title>
+        <para>The Autobuilder has Yocto Project-specific functionality to allow builds to operate
+            with increased efficiency and speed.</para>
+        <section id='test-clobberdir'>
+            <title>clobberdir</title>
+            <para>When deleting files, the Autobuilder uses <filename>clobberdir</filename>, which
+                is a special script that moves files to a special location, rather than deleting
+                them. Files in this location are deleted by an <filename>rm</filename> command,
+                which is run under <filename>ionice -c 3</filename>. For example, the deletion only
+                happens when there is idle IO capacity on the Worker. The Autobuilder Worker Janitor
+                runs this deletion. See <link linkend="test-autobuilder-worker-janitor">Autobuilder
+                    Worker Janitor</link>.</para>
+        </section>
+        <section id='test-autobuilder-clone-cache'>
+            <title>Autobuilder Clone Cache</title>
+            <para>Cloning repositories from scratch each time they are required was slow on the
+                Autobuilder. We therefore have a stash of commonly used repositories pre-cloned on
+                the Workers. Data is fetched from these during clones first, then "topped up" with
+                later revisions from any upstream when necesary. The cache is maintained by the
+                Autobuilder Worker Janitor. See <link linkend="test-autobuilder-worker-janitor"
+                    >Autobuilder Worker Janitor</link>.</para>
+        </section>
+        <section id='test-autobuilder-worker-janitor'>
+            <title>Autobuilder Worker Janitor</title>
+            <para>This is a process running on each Worker that performs two basic operations,
+                including background file deletion at IO idle (see <link
+                    linkend="test-list-tgt-exec-clobberdir">Target Execution: clobberdir</link>) and
+                maintainenance of a cache of cloned repositories to improve the speed the system can
+                checkout repositories.</para>
+        </section>
+        <section id='test-shared-dl-dir'>
+            <title>Shared DL_DIR</title>
+            <para>The Workers are all connected over NFS which allows DL_DIR to be shared between
+                them. This reduces network accesses from the system and allows the build to be sped
+                up. Usage of the directory within the build system is designed to be able to be
+                shared over NFS.</para>
+        </section>
+        <section id='test-shared-sstate-cache'>
+            <title>Shared SSTATE_DIR</title>
+            <para>The Workers are all connected over NFS which allows the
+                    <filename>sstate</filename> directory to be shared between them. This means once
+                a Worker has built an artefact, all the others can benefit from it. Usage of the
+                directory within the directory is designed for sharing over NFS.</para>
+        </section>
+        <section id='test-resulttool'>
+            <title>Resulttool</title>
+            <para>All of the different tests run as part of the build generate output into
+                    <filename>testresults.json</filename> files. This allows us to determine which
+                tests ran in a given build and their status. Additional information, such as failure
+                logs or the time taken to run the tests, may also be included.</para>
+            <para>Resulttool is part of OpenEmbedded-Core and is used to manipulate these json
+                results files. It has the ability to merge files together, display reports of the
+                test results and compare different result files.</para>
+            <para>For details, see <link linkend=""
+                    >https://wiki.yoctoproject.org/wiki/Resulttool</link>.</para>
+        </section>
+    </section>
+    <section id='test-run-config-tgt-execution'>
+        <title>run-config Target Execution</title>
+        <para>The <filename>scripts/run-config</filename> execution is where most of the work within
+            the Autobuilder happens. It runs through a number of steps; the first are general setup
+            steps that are run once and include:<orderedlist>
+                <listitem>
+                    <para>Set up any <filename>buildtools-tarball</filename> if configured.</para>
+                </listitem>
+                <listitem>
+                    <para>Call "buildhistory-init" if buildhistory is configured.</para>
+                </listitem>
+            </orderedlist></para>
+        <para>For each step that is configured in <filename>config.json</filename>, it will perform
+            the following:</para>
+        <para>
+            <remark>## WRITER's question: What does "logging in as stepXa" and others refer to
+                below? ##</remark>
+            <orderedlist>
+                <listitem id="test-run-config-add-layers-step">
+                    <para dir="ltr">Add any layers that are specified using the
+                            <filename>bitbake-layers add-layer</filename> command (logging as
+                        stepXa)</para>
+                </listitem>
+                <listitem>
+                    <para dir="ltr">Call the <filename>scripts/setup-config</filename> script to
+                        generate the necessary <filename>auto.conf</filename> configuration file for
+                        the build</para>
+                </listitem>
+                <listitem>
+                    <para dir="ltr">Run the <filename>bitbake BBTARGETS</filename> command (logging
+                        as stepXb)</para>
+                </listitem>
+                <listitem>
+                    <para dir="ltr">Run the <filename>bitbake SANITYTARGETS</filename> command
+                        (logging as stepXc)</para>
+                </listitem>
+                <listitem>
+                    <para dir="ltr">Run the <filename>EXTRACMDS</filename> command, which are run
+                        within the BitBake build environment (logging as stepXd)</para>
+                </listitem>
+                <listitem>
+                    <para dir="ltr">Run the <filename>EXTRAPLAINCMDS</filename> command(s), which
+                        are run outside the BitBake build environment (logging as stepXd)</para>
+                </listitem>
+                <listitem>
+                    <para dir="ltr">Remove any layers added in <link
+                            linkend="test-run-config-add-layers-step">step 1</link> using the
+                            <filename>bitbake-layers remove-layer</filename> command (logging as
+                        stepXa)</para>
+                </listitem>
+            </orderedlist>
+        </para>
+        <para>Once the execution steps above complete, <filename>run-config</filename> executes a
+            set of post-build steps, including:<orderedlist>
+                <listitem>
+                    <para dir="ltr">Call <filename>scripts/publish-artifacts</filename> to collect
+                        any output which is to be saved from the build.</para>
+                </listitem>
+                <listitem>
+                    <para dir="ltr">Call <filename>scripts/collect-results</filename> to collect any
+                        test results to be saved from the build.</para>
+                </listitem>
+                <listitem>
+                    <para dir="ltr">Call <filename>scripts/upload-error-reports</filename> to send
+                        any error reports generated to the remote server.</para>
+                </listitem>
+                <listitem>
+                    <para dir="ltr">Cleanup the build directory using <link
+                            linkend="test-clobberdir"><filename>clobberdir</filename></link> if the
+                        build was successful, else rename it to “build-renamed” for potential future
+                        debugging.</para>
+                </listitem>
+            </orderedlist></para>
+    </section>
+    <section id='test-deploying-yp-autobuilder'>
+        <title>Deploying Yocto Autobuilder</title>
+        <para>The most up to date information about how to setup and deploy your own Autbuilder can
+            be found in README.md in the <filename>yocto-autobuilder2</filename> repository.</para>
+        <para>We hope that people can use the <filename>yocto-autobuilder2</filename> code directly
+            but it is inevitable that users will end up needing to heavily customise the
+                <filename>yocto-autobuilder-helper</filename> repository, particularly the
+                <filename>config.json</filename> file as they will want to define their own test
+            matrix.</para>
+        <para>The Autobuilder supports wo customization options: <itemizedlist>
+                <listitem>
+                    <para>variable substitution</para>
+                </listitem>
+                <listitem>
+                    <para>overlaying configuration files</para>
+                </listitem>
+            </itemizedlist>The standard <filename>config.json</filename> minimally attempts to allow
+            substitution of the paths. The Helper script repository includes a
+                <filename>local-example.json</filename> file to show how you could override these
+            from a separate configuration file. Pass the following into the environment of the
+            Autobuilder:<literallayout>
+     $ ABHELPER_JSON="config.json local-example.json"
+                    </literallayout>As
+            another example, you could also pass the following into the
+            environment:<literallayout>
+     $ ABHELPER_JSON="config.json <replaceable>/some/location/</replaceable>local.json"
+                    </literallayout>One
+            issue users often run into is validation of the <filename>config.json</filename> files.
+            A tip for minimizing issues from invalid json files is to use a Git
+                <filename>pre-commit-hook.sh</filename> script to verify the JSON file before
+            committing it. Create a symbolic link as
+            follows:<literallayout>
+     $ ln -s ../../scripts/pre-commit-hook.sh .git/hooks/pre-commit
+                    </literallayout></para>
+    </section>
+
+
+
+
+
+
+
+
+</chapter>
+<!--
+vim: expandtab tw=80 ts=4
+-->

documentation/test-manual/test-manual.xml

@@ -0,0 +1,103 @@
+<!DOCTYPE book PUBLIC "-//OASIS//DTD DocBook XML V4.2//EN"
+"http://www.oasis-open.org/docbook/xml/4.2/docbookx.dtd"
+[<!ENTITY % poky SYSTEM "../poky.ent"> %poky; ] >
+
+<book id='test-manual' lang='en'
+      xmlns:xi="http://www.w3.org/2003/XInclude"
+      xmlns="http://docbook.org/ns/docbook"
+      >
+    <bookinfo>
+
+        <mediaobject>
+            <imageobject>
+                <imagedata fileref='figures/test-manual-title.png'
+                    format='SVG'
+                    align='left' scalefit='1' width='100%'/>
+            </imageobject>
+        </mediaobject>
+
+        <title>
+            Yocto Project Test Environment Manual
+        </title>
+
+        <authorgroup>
+            <author>
+                <affiliation>
+                    <orgname>&ORGNAME;</orgname>
+                </affiliation>
+                <email>&ORGEMAIL;</email>
+            </author>
+        </authorgroup>
+
+        <revhistory>
+            <revision>
+                <revnumber>3.1.1</revnumber>
+                <date>TBD</date>
+                <revremark>DRAFT - Work-in-Progress - posted June 16, 2020</revremark>
+            </revision>
+        </revhistory>
+
+    <copyright>
+     <year>&COPYRIGHT_YEAR;</year>
+      <holder>Linux Foundation</holder>
+    </copyright>
+
+    <legalnotice>
+      <para>
+          Permission is granted to copy, distribute and/or modify this document under
+          the terms of the <ulink type="http" url="http://creativecommons.org/licenses/by-sa/2.0/uk/">
+          Creative Commons Attribution-Share Alike 2.0 UK: England &amp; Wales</ulink> as published by
+          Creative Commons.
+      </para>
+           <note><title>Manual Notes</title>
+               <itemizedlist>
+                   <listitem><para>
+                       This version of the
+                       <emphasis>Yocto Project Test Environment Manual</emphasis>
+                       is for the &YOCTO_DOC_VERSION; release of the
+                       Yocto Project.
+                       To be sure you have the latest version of the manual
+                       for this release, go to the
+                       <ulink url='&YOCTO_HOME_URL;/documentation'>Yocto Project documentation page</ulink>
+                       and select the manual from that site.
+                       Manuals from the site are more up-to-date than manuals
+                       derived from the Yocto Project released TAR files.
+                       </para></listitem>
+                   <listitem><para>
+                       If you located this manual through a web search, the
+                       version of the manual might not be the one you want
+                       (e.g. the search might have returned a manual much
+                       older than the Yocto Project version with which you
+                       are working).
+                       You can see all Yocto Project major releases by
+                       visiting the
+                       <ulink url='&YOCTO_WIKI_URL;/wiki/Releases'>Releases</ulink>
+                       page.
+                       If you need a version of this manual for a different
+                       Yocto Project release, visit the
+                       <ulink url='&YOCTO_HOME_URL;/documentation'>Yocto Project documentation page</ulink>
+                       and select the manual set by using the
+                       "ACTIVE RELEASES DOCUMENTATION" or "DOCUMENTS ARCHIVE"
+                       pull-down menus.
+                       </para></listitem>
+                   <listitem><para>
+                       To report any inaccuracies or problems with this
+                       manual, send an email to the Yocto Project
+                       discussion group at
+                       <filename>yocto@yoctoproject.com</filename> or log into
+                       the freenode <filename>#yocto</filename> channel.
+                       </para></listitem>
+               </itemizedlist>
+           </note>
+    </legalnotice>
+
+    </bookinfo>
+
+    <xi:include href="test-manual-intro.xml"/>
+    <xi:include href="test-manual-test-process.xml"/>
+    <xi:include href="test-manual-understand-autobuilder.xml"/>
+
+</book>
+<!--
+vim: expandtab tw=80 ts=4
+-->
