@@ -41,181 +41,253 @@
|
|
|
</para>
|
|
|
</section>
|
|
|
|
|
|
- <section id="platdev-appdev-external-anjuta">
|
|
|
- <title>Developing externally using the Anjuta plugin</title>
|
|
|
-
|
|
|
- <para>
|
|
|
- An Anjuta IDE plugin exists to make developing software within the Poky framework
|
|
|
- easier for the application developer. It presents a graphical IDE from which the
|
|
|
- developer can cross compile an application then deploy and execute the output in a QEMU
|
|
|
- emulation session. It also supports cross debugging and profiling.
|
|
|
- </para>
|
|
|
-<!-- DISBALED, TOO BIG!
|
|
|
- <screenshot>
|
|
|
- <mediaobject>
|
|
|
- <imageobject>
|
|
|
- <imagedata fileref="screenshots/ss-anjuta-poky-1.png" format="PNG"/>
|
|
|
- </imageobject>
|
|
|
- <caption>
|
|
|
- <para>The Anjuta Poky SDK plugin showing an active QEMU session running Sato</para>
|
|
|
- </caption>
|
|
|
- </mediaobject>
|
|
|
- </screenshot>
|
|
|
--->
|
|
|
- <para>
|
|
|
- To use the plugin, a toolchain and SDK built by Poky is required along with Anjuta it's development
|
|
|
- headers and the Anjuta plugin. The Poky Anjuta plugin is available to download as a tarball at the
|
|
|
- <ulink url='http://labs.o-hand.com/anjuta-poky-sdk-plugin/'>OpenedHand labs</ulink> page or
|
|
|
- directly from the Poky Git repository located at git://git.pokylinux.org/anjuta-poky; a web interface
|
|
|
- to the repository can be accessed at <ulink url='http://git.pokylinux.org/?p=anjuta-poky.git;a=summary'/>.
|
|
|
- </para>
|
|
|
+ <section id="using-the-eclipse-and-anjuta-plug-ins">
|
|
|
+ <title>Using the Eclipse and Anjuta Plug-ins</title>
|
|
|
<para>
|
|
|
- See the README file contained in the project for more information on dependencies and building
|
|
|
- the plugin. If you want to disable remote gdb debugging, please pass --diable-gdb-integration
|
|
|
- switch when doing configure.
|
|
|
+ Yocto Project supports both Anjuta and Eclipse IDE plug-ins to make developing software
|
|
|
+ easier for the application developer. The plug-ins provide capability
|
|
|
+ extensions to the graphical IDE allowing for cross compilation,
|
|
|
+ deployment and execution of the output in a QEMU emulation session.
|
|
|
+ Support of these plug-ins also supports cross debugging and
|
|
|
+ profiling. Additionally, the Eclipse plug-in provides a suite of tools
|
|
|
+ that allows the developer to perform remote profiling, tracing, collection of
|
|
|
+ power data, collection of latency data and collection of performance data.
|
|
|
</para>
|
|
|
|
|
|
- <section id="platdev-appdev-external-anjuta-setup">
|
|
|
- <title>Setting up the Anjuta plugin</title>
|
|
|
-
|
|
|
- <para>Extract the tarball for the toolchain into / as root. The
|
|
|
- toolchain will be installed into
|
|
|
- <filename class="directory">/opt/poky</filename>.</para>
|
|
|
-
|
|
|
- <para>To use the plugin, first open or create an existing
|
|
|
- project. If creating a new project the "C GTK+" project type
|
|
|
- will allow itself to be cross-compiled. However you should be
|
|
|
- aware that this uses glade for the UI.</para>
|
|
|
-
|
|
|
- <para>To activate the plugin go to
|
|
|
- <menuchoice><guimenu>Edit</guimenu><guimenuitem>Preferences</guimenuitem></menuchoice>,
|
|
|
- then choose <guilabel>General</guilabel> from the left hand side. Choose the
|
|
|
- Installed plugins tab, scroll down to <guilabel>Poky
|
|
|
- SDK</guilabel> and check the
|
|
|
- box. The plugin is now activated but first it must be
|
|
|
- configured.</para>
|
|
|
- </section>
|
|
|
-
|
|
|
- <section id="platdev-appdev-external-anjuta-configuration">
|
|
|
- <title>Configuring the Anjuta plugin</title>
|
|
|
-
|
|
|
- <para>The configuration options for the SDK can be found by choosing
|
|
|
- the <guilabel>Poky SDK</guilabel> icon from the left hand side. The following options
|
|
|
- need to be set:</para>
|
|
|
-
|
|
|
- <itemizedlist>
|
|
|
-
|
|
|
- <listitem><para><guilabel>SDK root</guilabel>: If we use external toolchain, we need to set SDK root.
|
|
|
- this is the root directory of the SDK's sysroot. For an i586 SDK this will be <filename
|
|
|
- class="directory">/opt/poky/</filename>.
|
|
|
- This directory will contain directories named like "bin",
|
|
|
- "include", "var", etc. under your selected target architecture subdirectory<filename class="directory">
|
|
|
- /opt/poky/sysroot/i586-poky-linux/</filename>. Needed cross compile tools are under
|
|
|
- <filename class ="directory">/opt/poky/sysroot/i586-pokysdk-linux/</filename>
|
|
|
- </para></listitem>
|
|
|
-
|
|
|
- <listitem><para><guilabel>Poky root</guilabel>: If we have local poky build tree, we need to set the Poky root.
|
|
|
- this is the root directory of the poky build tree, if you build your i586 target architecture
|
|
|
- under the subdirectory of build_x86 within your poky tree, the Poky root directory should be
|
|
|
- <filename class="directory">${Poky_tree}/build_x86/</filename>.
|
|
|
- </para></listitem>
|
|
|
-
|
|
|
- <listitem><para><guilabel>Target Architecture</guilabel>: this is the cross compile
|
|
|
- triplet, e.g. "i586-poky-linux". This target triplet is the prefix extracted from
|
|
|
- the set up script file name. For examle, "i586-poky-linux" is extracted from set up script file
|
|
|
- <filename>/opt/poky/environment-setup-i586-poky-linux</filename>
|
|
|
- </para></listitem>
|
|
|
-
|
|
|
- <listitem><para><guilabel>Kernel</guilabel>: use the file chooser to select the kernel
|
|
|
- to use with QEMU</para></listitem>
|
|
|
-
|
|
|
- <listitem><para><guilabel>Root filesystem</guilabel>: use the file chooser to select
|
|
|
- the root filesystem directory, this is the directory where you use "poky-extract-sdk" command to
|
|
|
- extract the poky-image-sdk tarball.</para></listitem>
|
|
|
- </itemizedlist>
|
|
|
-<!-- DISBALED, TOO BIG!
|
|
|
- <screenshot>
|
|
|
- <mediaobject>
|
|
|
- <imageobject>
|
|
|
- <imagedata fileref="screenshots/ss-anjuta-poky-2.png" format="PNG"/>
|
|
|
- </imageobject>
|
|
|
- <caption>
|
|
|
- <para>Anjuta Preferences Dialog</para>
|
|
|
- </caption>
|
|
|
- </mediaobject>
|
|
|
- </screenshot>
|
|
|
--->
|
|
|
+ <section id="the-eclipse-plug-in">
|
|
|
+ <title>The Eclipse Plug-in</title>
|
|
|
+ <para>
|
|
|
+ To use the Eclipse plug-in, a toolchain and SDK built by Poky is required along with
|
|
|
+ the Eclipse Framework (Helios 3.6).
|
|
|
+ To install the plug-in you need to be in the Eclipse IDE and select
|
|
|
+ the following menu:
|
|
|
+ <literallayout class='monospaced'>
|
|
|
+ Help -> Install New Software
|
|
|
+ </literallayout>
|
|
|
+ Specify the target URL as http://yocto./download (real link needed).
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ If you want to download the source code for the plug-in you can find it in the Poky
|
|
|
+ git repository, which has a web interface, and is located at
|
|
|
+ <ulink url="http://git.pokylinux.org/cgit.cgi/eclipse-poky"></ulink>.
|
|
|
+ </para>
|
|
|
+
|
|
|
+ <section id="installing-and-setting-up-the-eclipse-ide">
|
|
|
+ <title>Installing and Setting up the Eclipse IDE</title>
|
|
|
+ <para>
|
|
|
+ If you don't have the Eclipse IDE (Helios 3.6) on your system you need to
|
|
|
+ download and install it from <ulink url="http://www.eclipse.org/downloads"></ulink>.
|
|
|
+ Choose the Eclipse Classic, which contains the Eclipse Platform, Java Development
|
|
|
+ Tools (JDT), and the Plug-in Development Environment.
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ NOTE: Due to the Java Virtual Machine's garbage collection (GC) process the
|
|
|
+ permanent generation space (PermGen) is not cleaned up. This space is used
|
|
|
+ to store meta-data descriptions of classes. The default value is set too small
|
|
|
+ and it could trigger an out of memory error like the following:
|
|
|
+ <literallayout class='monospaced'>
|
|
|
+ Java.lang.OutOfMemoryError: PermGen space
|
|
|
+ </literallayout>
|
|
|
+ This error causes the applications to hang.
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ To fix this issue you can use the <command>-vmargs</command>
|
|
|
+ option when you start Eclipse to increase the size of the permenant generation space:
|
|
|
+ <literallayout class='monospaced'>
|
|
|
+ Eclipse -vmargs -XX:PermSize=256M
|
|
|
+ </literallayout>
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ The Eclipse plug-in depends several Eclipse projects plug-ins:
|
|
|
+ Eclipse C/C++ Development Tools (CDT), Autotools support for CDT (Incubation) and Target
|
|
|
+ Management (RSE).
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ After installing Eclipse and bringing up the IDE for the first
|
|
|
+ time you need to be sure the following four sites are available by adding them.
|
|
|
+ </para>
|
|
|
+ <itemizedlist>
|
|
|
+ <listitem>CDT - http://download.eclipse.org/tools/cdt/releases/helios</listitem>
|
|
|
+ <listitem>Helios - http://download.eclipse.org/releases/helios</listitem>
|
|
|
+ <listitem>Target Management
|
|
|
+ 3.2 Updates - http://download.eclipse.org/dsdp/tm/updates/3.2</listitem>
|
|
|
+ <listitem>The Eclipse Project Updates -
|
|
|
+ http://download.eclipse.org/eclipse/updates/3.6</listitem>
|
|
|
+ </itemizedlist>
|
|
|
+ <para>
|
|
|
+ Once these sites are available do the following:
|
|
|
+ <itemizedlist>
|
|
|
+ <listitem>Use the "Work with:" drop down list and
|
|
|
+ select "All Available Sites--"</listitem>
|
|
|
+ <listitem><emphasis>For CDT and Autotools support:</emphasis> Expand the
|
|
|
+ "Programming Languages" list and select "Autotools support for CDT
|
|
|
+ (Incubation)" and "C/C++ Development Tools". Click "Next" and complete
|
|
|
+ the update.</listitem>
|
|
|
+ <listitem><emphasis>For RSE support:</emphasis> Select "TM and
|
|
|
+ RSE Main Features". Click "Next" and complete the update.</listitem>
|
|
|
+ </itemizedlist>
|
|
|
+ </para>
|
|
|
+ </section>
|
|
|
|
|
|
+ <section id="installing-the-yocto-plug-in">
|
|
|
+ <title>Installing the Yocto Plug-in</title>
|
|
|
+ <para>
|
|
|
+ Once you have the Eclipse IDE installed and configure you need to install the
|
|
|
+ Yocto plug-in. You do this similar to installing the Eclipse plug-ins in the
|
|
|
+ previous section.
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ Do the following to install the Yocto plug-in into the Eclipse IDE:
|
|
|
+ <itemizedlist>
|
|
|
+ <listitem>Select the "Help -> Install New Software" item.</listitem>
|
|
|
+ <listitem>In the "Work with:" area click "Add..." and enter the URL for
|
|
|
+ the Yocto plug-in (we need to supply this URL).</listitem>
|
|
|
+ <listitem>Finish out the installation of the update similar to any other
|
|
|
+ Eclipse plug-in.</listitem>
|
|
|
+ </itemizedlist>
|
|
|
+ </para>
|
|
|
+ </section>
|
|
|
+
|
|
|
+ <section id="configuring-yocto-eclipse-plug-in">
|
|
|
+ <title>Configuring Yocto Eclipse plug-in</title>
|
|
|
+ <para>
|
|
|
+ To configure the Yocto Eclipse plug-in you need to select the mode and then the
|
|
|
+ architecture with which you will be working. Start by selecting "Preferences"
|
|
|
+ from the "Window" menu and then selecting "Yocto SDK".
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ If you normally will use an installed Yocto
|
|
|
+ SDK (under /opt/poky) select “SDK Root Mode”. Otherwise, if your crosstool chain
|
|
|
+ and sysroot are within your poky tree, select “Poky Tree Mode”.
|
|
|
+ If you are in SDK Root Mode you will need to provide your poky tree path, for
|
|
|
+ example, $<Poky_tree>/build/.
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ Now you need to select the architecture.
|
|
|
+ Use the drop down list and select the architecture that you’ll be primarily
|
|
|
+ working against.
|
|
|
+ For target option, select your typical target QEMU vs External HW. If you
|
|
|
+ choose QEMU, you’ll need to specify your QEMU kernel file with full path and the
|
|
|
+ rootfs mount point. Yocto QEMU boots off user mode NFS, Please refer to QEMU
|
|
|
+ section for how to set it up. (Section TBD)
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ Save all your settings and they become your defaults for every new Yocto project
|
|
|
+ created using the Eclipse IDE.
|
|
|
+ </para>
|
|
|
+ </section>
|
|
|
+
|
|
|
+ <section id="using-the-yocto-eclipse-plug-in">
|
|
|
+ <title>Using the Yocto Eclipse Plug-in</title>
|
|
|
+ <para>
|
|
|
+ As an example, this section shows you how to cross-compile a Yocto C autotools
|
|
|
+ based project, deploy it into QEMU, and then run the debugger against it.
|
|
|
+ You need to configure the project, trigger <command> autogen.sh</command>, build
|
|
|
+ the image, start QEMU, and then debug.
|
|
|
+ </para>
|
|
|
+ <orderedlist>
|
|
|
+ <listitem>Creating a Yocto Autotools Based Project Using a Template:
|
|
|
+ Get to the Wizard selection by selecting the File -> New -> Project
|
|
|
+ menu. Expand "C/C++" and select "C Project". Click "Next" and select a template
|
|
|
+ to start with, for example "Hello World ANSI C Project". Complete the steps
|
|
|
+ to create a new Yocto autotools based project using this template.</listitem>
|
|
|
+ <listitem>Specify Specific Toolchain Configurations: By default the project
|
|
|
+ uses the Yocto preferences settings as defined using the procedure in
|
|
|
+ <link linkend="configuring-yocto-eclipse-plug-in"> the previous section</link>.
|
|
|
+ If there are any specific setup requirements for the newly created project
|
|
|
+ you need to reconfigure the Yocto plug-in through the menu selection
|
|
|
+ Project -> Invoke Yocto Tools -> Reconfigure Yocto. Use this dialogue
|
|
|
+ to specify specific toolchain and QEMU setups for the project.</listitem>
|
|
|
+ <listitem>Building the Project: Trigger <command>autogen.sh</command> through
|
|
|
+ Project -> Reconfigure Project. Then build the project using
|
|
|
+ Project -> Build.</listitem>
|
|
|
+ <listitem>Starting QEMU: Use the Run -> External Tools menu and see if there is
|
|
|
+ a QEMU instance for the desired target. If there is click on the instance
|
|
|
+ to start QEMU. If your target is not there then click "External Tools
|
|
|
+ Configuration". You should find an instance of QEMU for your architecture
|
|
|
+ under the entry under "Program". After the boot completes you are ready to
|
|
|
+ deploy the image into QEMU.</listitem>
|
|
|
+ <listitem>Debugging: To bring up your remote debugging configuration in the
|
|
|
+ right-hand window highlight your project in “Project Explorer”, select
|
|
|
+ the Run -> Debug Configurations menu item and expand “C/C++ Remote Application”.
|
|
|
+ Next, select projectname_ gdb_target-poky-linux.
|
|
|
+ You need to be sure that there is an
|
|
|
+ entry for the remote target you want to deploy and cross debug with. If there
|
|
|
+ is no entry then click "New..." to bring up the wizard. Using the wizard
|
|
|
+ select TCF and enter the IP address of you remote target in the
|
|
|
+ “Host name:” field. Back in the remote debug configure window,
|
|
|
+ you need to specify the absolute path for the program on the remote target
|
|
|
+ in the “Remote Absolute File Path for C/C++ Application” field. By default,
|
|
|
+ the program deploys into the remote target. If you don't want this then check
|
|
|
+ “Skip download to target path”. Finally, click "Debug” to start the remote
|
|
|
+ debugging session.</listitem>
|
|
|
+ </orderedlist>
|
|
|
+ </section>
|
|
|
+
|
|
|
+ <section id="using-yocto-eclipse-plug-in-remote-tools-suite">
|
|
|
+ <title>Using Yocto Eclipse plug-in Remote Tools Suite</title>
|
|
|
+ <para>
|
|
|
+ Remote tools let you do things like perform system profiling, kernel tracing,
|
|
|
+ examine power consumption, and so forth. To see and access the remote tools use the
|
|
|
+ Window -> YoctoTools menu.
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ Once you pick a tool you need to configure it for the remote target. Every tool
|
|
|
+ needs to have the connection configured. You have to select an existing TCF-based
|
|
|
+ RSE connection to the remote target. If one does not exist you need to create one
|
|
|
+ by clicking "New"
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ Here are some specifics about the remote tools:
|
|
|
+ <itemizedlist>
|
|
|
+ <listitem>Oprofile: Selecting this tool causes the oprofile-server on the remote
|
|
|
+ target to launch on the local host machine. To use the oprofile the oprofile-viewer
|
|
|
+ must be installed on the local host machine and the oprofile-server must be
|
|
|
+ installed on the remote target.</listitem>
|
|
|
+ <listitem>lttng: Selecting this tool runs ustrace on the remote target, transfers
|
|
|
+ the output data back to the local host machine and uses lttv-gui to graphically
|
|
|
+ display the output. To use this tool the lttv-gui must be installed on the
|
|
|
+ local host machine. See <ulink url="http://lttng.org/files/ust/manual/ust.html">
|
|
|
+ </ulink> for information on how to use <command>lttng</command> to trace an
|
|
|
+ application.
|
|
|
+ <para>
|
|
|
+ For "Application" you must supply the absolute path name to the application to
|
|
|
+ be traced by user mode lttng. For example, typing <command>/path/to/foo"
|
|
|
+ </command> triggers <command>usttrace /path/to/foo</command> on the
|
|
|
+ remote target to trace the program <command>/path/to/foo</command>.
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ "Argument" is passed to "usttrace" running on the remote target.
|
|
|
+ </para>
|
|
|
+ </listitem>
|
|
|
+ <listitem>powertop: Selecting this tool runs <command>powertop</command> on the
|
|
|
+ remote target machine and displays the result in a new view called "powertop".
|
|
|
+ <para>
|
|
|
+ "Time to gather data(sec):" is the time passed in seconds before data is
|
|
|
+ gathered from the remote target for analysis.
|
|
|
+ </para>
|
|
|
+ <para>
|
|
|
+ "show pids in wakeups list:" corresponds to the <command>-p</command>
|
|
|
+ argument passed to <command>powertop</command>
|
|
|
+ </para>
|
|
|
+ </listitem>
|
|
|
+ <listitem>latencytop and perf: The <command>latencytop</command> identifies
|
|
|
+ system latency, while <command>perf</command> monitors the system's performance
|
|
|
+ counter registers. Selecting either of these tools causes an RSE
|
|
|
+ terminal view to appear in which you can run the tools. Both tools refresh the
|
|
|
+ entire screen to display results while they run.</listitem>
|
|
|
+ </itemizedlist>
|
|
|
+ </para>
|
|
|
+ </section>
|
|
|
</section>
|
|
|
|
|
|
- <section id="platdev-appdev-external-anjuta-usage">
|
|
|
- <title>Using the Anjuta plugin</title>
|
|
|
-
|
|
|
- <para>As an example, cross-compiling a project, deploying it into
|
|
|
- QEMU and running a debugger against it and then doing a system
|
|
|
- wide profile.</para>
|
|
|
-
|
|
|
- <para>Choose <menuchoice><guimenu>Build</guimenu><guimenuitem>Run
|
|
|
- Configure</guimenuitem></menuchoice> or
|
|
|
- <menuchoice><guimenu>Build</guimenu><guimenuitem>Run
|
|
|
- Autogenerate</guimenuitem></menuchoice> to run "configure"
|
|
|
- (or to run "autogen") for the project. This passes command line
|
|
|
- arguments to instruct it to cross-compile.</para>
|
|
|
-
|
|
|
- <para>Next do
|
|
|
- <menuchoice><guimenu>Build</guimenu><guimenuitem>Build
|
|
|
- Project</guimenuitem></menuchoice> to build and compile the
|
|
|
- project. If you have previously built the project in the same
|
|
|
- tree without using the cross-compiler you may find that your
|
|
|
- project fails to link. Simply do
|
|
|
- <menuchoice><guimenu>Build</guimenu><guimenuitem>Clean
|
|
|
- Project</guimenuitem></menuchoice> to remove the old
|
|
|
- binaries. You may then try building again.</para>
|
|
|
-
|
|
|
- <para>Next start QEMU by using
|
|
|
- <menuchoice><guimenu>Tools</guimenu><guimenuitem>Start
|
|
|
- QEMU</guimenuitem></menuchoice>, this will start QEMU and
|
|
|
- will show any error messages in the message view. Once Poky has
|
|
|
- fully booted within QEMU you may now deploy into it.</para>
|
|
|
-
|
|
|
- <para>Once built and QEMU is running, choose
|
|
|
- <menuchoice><guimenu>Tools</guimenu><guimenuitem>Deploy</guimenuitem></menuchoice>,
|
|
|
- this will install the package into a temporary directory and
|
|
|
- then copy using rsync over SSH into the target. Progress and
|
|
|
- messages will be shown in the message view.</para>
|
|
|
-
|
|
|
- <para>To debug a program installed into onto the target choose
|
|
|
- <menuchoice><guimenu>Tools</guimenu><guimenuitem>Debug
|
|
|
- remote</guimenuitem></menuchoice>. This prompts for the
|
|
|
- local binary to debug and also the command line to run on the
|
|
|
- target. The command line to run should include the full path to
|
|
|
- the to binary installed in the target. This will start a
|
|
|
- gdbserver over SSH on the target and also an instance of a
|
|
|
- cross-gdb in a local terminal. This will be preloaded to connect
|
|
|
- to the server and use the <guilabel>SDK root</guilabel> to find
|
|
|
- symbols. This gdb will connect to the target and load in
|
|
|
- various libraries and the target program. You should setup any
|
|
|
- breakpoints or watchpoints now since you might not be able to
|
|
|
- interrupt the execution later. You may stop
|
|
|
- the debugger on the target using
|
|
|
- <menuchoice><guimenu>Tools</guimenu><guimenuitem>Stop
|
|
|
- debugger</guimenuitem></menuchoice>.</para>
|
|
|
-
|
|
|
- <para>It is also possible to execute a command in the target over
|
|
|
- SSH, the appropriate environment will be be set for the
|
|
|
- execution. Choose
|
|
|
- <menuchoice><guimenu>Tools</guimenu><guimenuitem>Run
|
|
|
- remote</guimenuitem></menuchoice> to do this. This will open
|
|
|
- a terminal with the SSH command inside.</para>
|
|
|
-
|
|
|
- <para>To do a system wide profile against the system running in
|
|
|
- QEMU choose
|
|
|
- <menuchoice><guimenu>Tools</guimenu><guimenuitem>Profile
|
|
|
- remote</guimenuitem></menuchoice>. This will start up
|
|
|
- OProfileUI with the appropriate parameters to connect to the
|
|
|
- server running inside QEMU and will also supply the path to the
|
|
|
- debug information necessary to get a useful profile.</para>
|
|
|
-
|
|
|
+ <section id="external-development-using-the-anjuta-plug-in">
|
|
|
+ <title>External Development Using the Anjuta Plug-in</title>
|
|
|
+ <para>
|
|
|
+ (Note: We will stop Anjuta plug-in support after Yocto project 0.9 release. Its source
|
|
|
+ code can be downloaded from git respository listed below, and free for the community to
|
|
|
+ continue supporting it moving forward.)
|
|
|
+ </para>
|
|
|
</section>
|
|
|
</section>
|
|
|
|
Richard Purdie
